FIND

Employing a mix of traditional exterior design elements with modern power-saving technologies, the FIND series offers exceptional energy efficiency for faster ROI while providing an aesthetic appeal.

规格参数


功率范围

20-120W


光效

120-160lm/W


产品特征

IP65/UL/ CUL/ DLC/ LM79/ CB/ CE/ RoHS


认证

IP67/UL/CUL/DLC/LM79/SAA/ENEC/ CB/CE/ErP/RoHS/PSE/IK08


适用场所

Street/Roadway/Parking lot/Area lighting

产品详细


01.HOUSING
Single-cast aluminum housing enables passive heat dissipation along the entire length of the luminaire.
Modular design allows for easy installation, replacement and maintenance.
02.FINISH
Corrosion resistant polyester powder painted 100μm thickness.
Meets a 1000-hour salt spray certification per ASTM B117/ ISO 9227:2012.
03.LED & OPTICAL ASSEMBLY
Each PCB are mounted with a TVS (Transient Voltage Suppressors) to protect the LEDs from voltage transients induced by lightning and other transient voltage events.
High-uniformity LED optics are constructed of durable optical polycarbonate that is
impact and UV resistant.
The metal plate provides double protection for the LED light engine and prolongs LED optics life.
Multiple optical lenses are available.
Each LED module are 100% tested prior to assembly which is IP65 rated.
04.MOUNTING
Side-entry mounting
0 and +5 degree of titling angle adjustment.
Adjustable for 1 5/8-2 3/8"(42mm-60mm) O.D. tenon.
Brackets are available for different installations.
05.Electrical/ Key Components/ Controls
120-277VAC and 12-24VDC available.
Surge protection to 20kV/10kA per ANSI/IEEE C62.41.2-2002 available.
High quality LEDs, driver and components, e.g. MOLEX, WAGO connectors.
Multiple smart lighting control options are available, e.g. photocell, 1-10V.
3-pin/ 5-pin/ 7-pin photocell are available for light level adjustments.

  • 关键词:
    • Street light
    • Streetlights
    • LED street light
    • Hot sell SAA IK08 IP66 LM79 60w outdoor street Lighting
    • ed fixture LED street lights
    • LED solar street light
    • LED street light with photocell
    • LED road and street lighting
    • public roads and highways lighting

文件下载


  • pdf
    FIND SERIES-1.pdf
    FIND SERIES-1.pdf
  • FIND Series IES File.zip
